Frequency range 400MHz--430MHz \ 440MHz¡ª470MHz
Frequency Circuit PTT Circuit
Operating Mode F3E
Operation mode Simplex of co-frequency or alien frequency
Operating temperature range -30¡æ to +60¡æ
Rated Voltage DC 7.4V¡À15%
Antenna impedance 50¦¸
Operation Distance 3-15km
Size 98¡Á52¡Á32mm(no including antenna)
Weight 220g(including battery)
Transmitter
RF power output 3W
Frequency Stability ¡À2.5ppm
Maximum Frequency offset ¡Ü5KHz
Radiation ¡Ü-60dB
Modulation Distortion £¼5%(300Hz-3KHz)
Transmitting current ¡Ü1100mA \ ¡Ü900mA
Receiver
Circuitry Double Super Heterodyne
Intermediate Freq.
1st IF 38.850MHz
2nd IF 450KHz
Reference sensitivity £¼0.15uV(12dB SINDA)
Squelch sensitivity £¼0.12uV
Squelch programable
Audio power ¡Ý500mW
Receiving current £¼100mA
Squelch waiting current 20mA
