Model No. YUE-6100
Features:
¡ñ 128 Stored Channels
¡ñ CTCSS\ DCS Function
¡ñ handheld VOX Function
¡ñ Channel scan
¡ñ PC Program
¡ñ Wire Clone Function
¡ñ Password protection function
¡ñ H/M/L power shift <5W/3W/1W>
¡ñ FM Radios function
Technical Specifications:
Frequency Range 136-174MHZ , 400-470MHZ
Freq.Circuit PLL Circuit
MODE F3E
Form With the frequently single worker or the different single worker frequently
Antenna Impedance 50A
Step size 5,6.25KHZ
DV Voltage DC7.4V¡À15%
Operation Temperature -30¡ãC~+60¡ãC
Distances 3-15KM(Open ground)
Channel No. 128 channel
Dimensions 98(L)*53(W)*23(D)MM
Weight 195G£¨Include the lithium battery group£©
Transmitter
Power Output 5W
Moudulation Distortion <5%(300KHz-3KHz)
Max.Freq.Deviation <¡À5KHz
Spurious Radiation ¡À2.5PPM
Freq.Stability 6dB
Transmitting Current ¡Ü1300mA
Receiver
Circuitry Double Super Heterodyne
Intermediate Freq. ~
1st 1F 38.850MHz
2nd 1F 450MHz
Sensitivity <0.18¦ÌV(12dB SINAD)
Squelch Sensitivity <0.16¦ÌV
Squelch Programable
Audio Power ¡Ý500mW
Receiving Current <100mV
Standby 20mA
