Time-Out Timer(TOT)
TOT will prevent any individual from using a channel for extended
period nby
setting continuous transmission time.

Busy Channel Lockout
It prevents you from interfering with using channel.

Power Save Function
Power save function deceases the power consumption when no
signal is being received and no operation is being performed.

Frequency Range 400-430MHZ  , 440-470MHZ
Freq.Circuit PLL Circuit
MODE F3E
Form With the frequently single worker or the different single worker frequently
Antenna Impedance 50Ω
Step size 5,6.25KHZ
DV Voltage DC7.4V±15%
Operation Temperature -30°C~+60°C
Distances 3-15KM(Open ground)
Channel No. 16channel
Dimensions 95(L)*58(W)*32(D)MM
Weight 195G（Include the lithium battery group）

Transmitter
Power Output 5W
Moudulation Distortion <5%(300KHz-3KHz)
Max.Freq.Deviation <±5KHz
Spurious Radiation  ±2.5PPM
Freq.Stability 6dB
Transmitting Current ≤1300mA

Receiver
Circuitry Double Super Heterodyne
Intermediate Freq. ~
1st 1F 38.850MHz
2nd 1F 450MHz
Sensitivity <0.18μV(12dB SINAD)
Squelch Sensitivity <0.16μV
Squelch Programable
Audio Power ≥500mW
Receiving Current <100mV
Standby 20mA
