Band: A 26065-26505KHz
B 26515-26955KHz
C 26965-27405KHz
D 27415-27855KHz
E 27865-28305KHz
F 28315-28755KHz
Number of Channels 240channels can be received for European network
Type of Modulation Frequency modulation/Amplitude Modulation
Resistance of antenna 50 Ohm
three regulating knobs and switches:
Volume adjusting knob(with power switch),noise reduction regulating knob,channel adjustment knob(UP,Down).
Signal strength adjustment knob,various switches:
NB,DW,CH9,SCAN,AM/FM,memory channel 1,2,3,4
Speaker 84MM;8 Ohm; 1.0W
Microphone Capacitor microphone
Power voltage 13.8V
Outline dimension 159*139*48mm
Weight 850g
In order to improve the reliability of radio control system,contactless diode and audion power supply system is applied.
The protection device of the transmitter prevents maladjustment, short circuit and broken of antenna wiring due to over
current.
Built-in filter is installed in the power cord,which can eliminate inference of the igniting device of th vehicle.
Receiver
Sensitivity under 10ab signal noise ratio 0.8ab/mkw(AM); 0.5mkw(FM)
Selection performance 60 db Band With 5Khz
Band AGC 80db
Noise control scope 0.5mkw-1000mkw
Sound input power 1.0W in 8Ohm with 10% distortion
Distortion will not be over %3 when the input signal is 1000mkw
Sound frequency scope 400-2400Hz
Range frequency 1-10695KHz
2-455KHz
Receiving selection performance of sub-channel not less than 45 ab
Transmitter
Transmiting power 8W
Frequency stability not more than 0.005%
Sub-transmitting level not more than 70 ab
Operating-current not more than 2.0A
Modulator specification AM90%(+/-5%)
Frequency modulation deviation 2.0Khz
